Pressurisation Equipment

Compact and enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on a sealed system to provide a minimum system pressure requirement.

The Flexfiller is a floor-standing, flow rate (up to 18 l/min) top-up pressurisation unit with an 18-litre internal break tank. Ideal for Industrial, commercial or large domestic applications. Available in single or twin pump configuration.

Application: Commercial, Industrial and Residential.

System Volume (Guide): < 300,000 litres.

Product Features:

• For system volumes up to 300,000 litres.
• Fluid Protection Category 5 (AB Weir Overflow).
• System fill mode.
• Onscreen Service Reminder - 12 Months.
• Electric pump, 230V 50Hz 1ph (2160D: 415V 50Hz 3ph).
• Colour: Black (RAL 9005).
• MODBUS RTU Communication Protocol.
• Password protected.
• Sequential programming menu.
• Pressure setting in 0.1 bar increments.
• Pump pulse option.
• Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
• Event logging: Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
• Volt-free contacts: Common Alarm (N/C), High Pressure Alarm (N/O), Low Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).

Compact and enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on a sealed system to provide a minimum system pressure requirement.

The Flexfiller Midi is a wall-mounted, flow rate (up to 12 l/min) top-up pressurisation unit with a 4-litre internal break tank. Ideal for Industrial, commercial or large domestic applications. Available in single or twin pump configuration.

Application: Commercial, Industrial and Residential.

System Volume (Guide): < 50,000 litres.

Product Features:

• For system volumes up to 50,000 litres.
• Fluid Protection Category 5 (AB Weir Overflow).
• System fill mode.
• Onscreen Service Reminder - 12 Months.
• Electric pump, 230V 50Hz 1ph.
• Colour: White (RAL 9003).
• MODBUS RTU Communication Protocol.
• Password protected.
• Sequential programming menu.
• Pressure setting in 0.1 bar increments.
• Pump pulse option.
• Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
• Event logging: Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
• Volt-free contacts: Common Alarm (N/C), High Pressure Alarm (N/O), Low Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).

Compact and enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on a sealed system to provide a minimum system pressure requirement.

The Digifiller is a wall-mounted, flow rate (up to 12 l/min) top-up pressurisation unit with a 4-litre internal break tank. Self-venting pumps and preset options to remove the need for conventional commissioning of the Pressurisation Unit. Ideal for Industrial, commercial or large domestic applications. Available preset to 0.5 bar, 1.0 bar, 1.5 bar or 2.0 bar top-up (Delivery) pressure.

Application: Commercial, Industrial and Residential.

System Volume (Guide): < 50,000 litres.

Product Features:

• For system volumes up to 50,000 litres.
• Fluid Protection Category 5 (AB Weir Overflow).
• Pre-commissioned.
• Pre-set (Bar).
• Plug & play, but easily adjustable on site if required.
• Self-bleed pump.
• System fill mode.
• Onscreen Service Reminder - 12 Months.
• Electric pump, 230V 50Hz 1ph.
• Colour: White (RAL 9003).
• MODBUS RTU Communication Protocol.
• Password protected.
• Sequential programming menu.
• Pressure setting in 0.1 bar increments.
• Pump pulse option.
• Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
• Event logging: Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
• Volt-free contacts: Common Alarm (N/C), High Pressure Alarm (N/O), Low Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).

Compact and enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on a sealed system to provide a minimum system pressure requirement.

The Flexfiller Twin System is a floor-standing unit, ideal where space restrictions make it beneficial to locate two systems in a single enclosure. The system combines two high flow rate (<18 l/min) top-up pressurisation units and two controllers with a single 18-litre break tank.

Application: Commercial, Industrial and Residential.

System Volume (Guide): < 300,000 litres per system.

Product Features:

• For system volumes up to 300,000 litres per system.
• Fluid Protection Category 5 (AB Weir Overflow).
• System fill mode.
• Onscreen Service Reminder - 12 Months.
• Electric pump, 230V 50Hz 1ph.
• Colour: Black (RAL 9005).
• MODBUS RTU Communication Protocol.
• Password protected.
• Sequential programming menu.
• Pressure setting in 0.1 bar increments.
• Pump pulse option.
• Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
• Event logging: Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
• Volt-free contacts: Common Alarm (N/C), High Pressure Alarm (N/O), Low Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).

Compact and enclosed digital pressurisation units with electronic pressure transducer and user-friendly microprocessor for use on a sealed system to provide a minimum system pressure requirement.

The PressDS (Pressurisation/Dosing System) is a floor-standing, additive top-up mixing pressurisation unit with a 4-litre break tank to be connected to the mains supply. 18-litre tank for additive storage. Each time the unit tops up the system with water, it also automatically adds an additive from a dedicated tank at a predetermined rate, reducing intervention and maximising system protection. The correct fluid mix is blended on demand at the time of system top-up. Available with double pump (for duty/standby configuration).

Application: Commercial and Industrial.

System Volume (Guide): < 300,000 litres.

Product Features:

• For system volumes up to 300,000 litres.
• Fluid Protection Category 5 (AB Weir Overflow).
• Mix ratios from 1% to 50% user user-configurable balancing valves.
• Top-up pressurisation unit (<18.0 l/min).
• System fill mode.
• Onscreen Service Reminder - 12 Months. Onscreen message when the additive tank is empty.
• Electric pump, 230V 50Hz 1ph.
• Colour: Black (RAL 9005)
• MODBUS RTU Communication Protocol.
• Password protected.
• Sequential programming menu.
• Pressure setting in 0.1 bar increments.
• Pump pulse option.
• Flood Protection (Pump Runtime Limiter, Excessive Start Alarm).
• Event logging: Alarm activations, Pump Run counter (activations per pump), Cumulative run timer (hours per pump), Electrical interruption.
• Volt-free contacts: Common Alarm (N/C), High Pressure Alarm (N/O), Low Pressure Alarm (N/O), Sensor Health (N/O), Pump 1 Health (N/O), Pump 2 Health (N/O).
