DOWNLOADS

Find Technical data and dimensions for our products through the quickview menu.

For more in depth information about our products view the product page.

PIPING SYSTEMS

KELOX MULTILAYER

Multilayer piping & Press fittings

stainless steel pipe and press fittings

STEELFIX

Stainless steel pipe & press fittings

Quick downloads

COPPER TUBE AND COPPER PRESS FITTINGS

COPPERFIX

Copper tube and copper press fittings

Quick downloads

DISTRICT HEATING AND DISTRICT COOLING

RADIUS KELIT

District heating and district cooling

Hot and cold water piping systems

KELEN

Hot and cold water piping systems

Quick downloads

Chilled water and compressed air piping

KETRIX

Chilled water and compressed air piping

Quick downloads

Metal to metal press connections

XTRME FIX

Metal to metal press connections

Quick downloads

Universal pipe insulation

LEXEL PIPE INSULATION SYSTEM

Universal pipe insulation

Quick downloads

PANEL RADIATORS

PANEL RADIATORS

Centrally connected radiator

T6 RADIATOR

Centrally connected radiators

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Full list of dimensions and outputs can be found in product downloads.


HxW = Output - 600x400 = 375.6

HxW = Output - 600x600 = 563.4

HxW = Output - 600x800 = 751.2

HxW = Output - 600x1000 = 939

HxW = Output - 600x1200 = 1126.8

HxW = Output - 600x1400 = 1314.6

HxW = Output - 600x1600 = 1502.4

HxW = Output - 600x1800 = 1690.2

HxW = Output - 400x600 = 628.2

HxW = Output - 400x800 = 837.6

HxW = Output - 400x1000 = 1047

HxW = Output - 400x1200 = 1256.4

HxW = Output - 400x1400 = 1465.8

HxW = Output - 400x1600 = 1675.2

HxW = Output - 400x1800 = 1884.6

HxW = Output - 400x2000 = 2094

HxW = Output - 400x2200 = 2303.4

HxW = Output - 400x2400 = 2512.8

HxW = Output - 500x400 = 490.8

HxW = Output - 500x600 = 736.2

HxW = Output - 500x800 = 981.6

HxW = Output - 500x1000 = 1227

HxW = Output - 500x1200 = 1472.4

HxW = Output - 500x1400 = 1717.8

HxW = Output - 500x1600 = 1963.2

HxW = Output - 500x1800 = 2208.6

HxW = Output - 500x2000 = 2454

HxW = Output - 500x2200 = 2699.4

HxW = Output - 500x2400 = 2944.8

HxW = Output - 500x2600 = 3190.2

HxW = Output - 500x2800 = 3435.6

HxW = Output - 500x3000 = 3681

HxW = Output - 600x400 = 542.8

HxW = Output - 600x600 = 814.2

HxW = Output - 600x800 = 1085.6

HxW = Output - 600x1000 = 1357

HxW = Output - 600x1200 = 1628.4

HxW = Output - 600x1400 = 1899.8

HxW = Output - 600x1600 = 2171.2

HxW = Output - 600x1800 = 2442.6

HxW = Output - 600x2000 = 2714

HxW = Output - 600x2200 = 2985.4

HxW = Output - 300x400 = 438

HxW = Output - 300x1000 = 1095

HxW = Output - 300x1200 = 1314

HxW = Output - 300x1400 = 1533

HxW = Output - 300x1600 = 1752

HxW = Output - 400x600 = 814.2

HxW = Output - 400x800 = 1085.6

HxW = Output - 400x1000 = 1357

HxW = Output - 400x1200 = 1628.4

HxW = Output - 400x1400 = 1899.8

HxW = Output - 400x1600 = 2171.2

HxW = Output - 400x1800 = 2442.6

HxW = Output - 400x2000 = 2714

HxW = Output - 400x2200 = 2985.4

HxW = Output - 600x600 = 1027.8

HxW = Output - 600x800 = 1370.4

HxW = Output - 600x1000 = 1713

HxW = Output - 600x1200 = 2055.6

HxW = Output - 600x1400 = 2398.2

HxW = Output - 600x1600 = 2740.8

HxW = Output - 600x1800 = 3083.4

HxW = Output - 600x2000 = 3426

HxW = Output - 600x2200 = 3768.6

HxW = Output - 900x400 = 918.4

HxW = Output - 900x600 = 1377.6

HxW = Output - 900x800 = 1836.8

HxW = Output - 600x600 = 1471.8

HxW = Output - 600x720 = 1766.16

HxW = Output - 600x800 = 1962.4

HxW = Output - 600x1000 = 2453

HxW = Output - 600x1200 = 2943.6

HxW = Output - 600x1400 = 3434.2

HxW = Output - 600x1600 = 3924.8

HxW = Output - 600x1800 = 4415.4

Low surface temperature radiators

LOW SURFACE TEMPERATURE RADIATORS

The radiators surface temperature does not exceed 43°C

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (∆T 50℃).

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


5_LS_80: 572 x 0800 = 277 Watts
5_LS_100: 572 x 1000 = 370 Watts
5_LS_120: 572 x 1200 = 462 Watts
6_LS_60: 672 x 0600 = 243 Watts
6_LS_80: 672 x 0800 = 365 Watts
6_LS_100: 672 x 1000 = 486 Watts
6_LS_120: 672 x 1200 = 608 Watts
6_LS_140: 672 x 1400 = 730 Watts
6_LS_160: 672 x 1600 = 851 Watts
6_LS_180: 672 x 1800 = 973 Watts
5_LSP_80: 572 x 0800 = 545 Watts
5_LSP_100: 572 x 1000 = 727 Watts
5_LSP_120: 572 x 1200 = 909 Watts
6_LSP_60: 672 x 0600 = 468 Watts
6_LSP_80: 672 x 0800 = 702 Watts
6_LSP_100: 672 x 1000 = 936 Watts
6_LSP_120: 672 x 1200 = 1170 Watts
6_LSP_140: 672 x 1400 = 1404 Watts
6_LSP_160: 672 x 1600 = 1638 Watts
6_LSP_180: 672 x 1800 = 1872 Watts
6_LSX_60: 672 x 0600 = 355 Watts
6_LSX_80: 672 x 0800 = 532 Watts
6_LSX_100: 672 x 1000 = 710 Watts
6_LSX_120: 672 x 1200 = 887 Watts
6_LSX_140: 672 x 1400 = 1064 Watts
6_LSX_160: 672 x 1600 = 1242 Watts
8_LSX_60: 872 x 0600 = 483 Watts
8_LSX_80: 872 x 0800 = 725 Watts
8_LSX_100: 872 x 1000 = 966 Watts
8_LSX_120: 872 x 1200 = 1208 Watts
Low temp radiators

ULOW-E2

Intelligent low temperature radiators

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (45/35/20) - 45℃ Flow Temperature, 35℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


TYPE22:
E2L2260004: 0600 x 400 = 272 Watts
E2L2260006: 0600 x 600 = 409 Watts
E2L2260008: 0600 x 800 = 545 Watts
E2L2260010: 0600 x 1000 = 681 Watts
E2L2260012: 0600 x 1200 = 817 Watts
E2L2260014: 0600 x 1400 = 953 Watts
E2L2260016: 0600 x 1600 = 1090 Watts
E2L2260018: 0600 x 1800 = 1226 Watts
E2L2260020: 0600 x 2000 = 1362 Watts





t6 plan radiator

T6-PLAN

Centrally connected radiators

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


T6P11300060: 300 x 0600 = 319 Watts
T6P11300080: 300 x 0800 = 426 Watts
T6P11300100: 300 x 1000 = 532 Watts
T6P11400060: 400 x 0600 = 396 Watts
T6P11400080: 400 x 0800 = 528 Watts
T6P11400100: 400 x 1000 = 660 Watts
T6P11600040: 600 x 0400 = 338 Watts
T6P11600060: 600 x 0600 = 506 Watts
T6P11600080: 600 x 0800 = 675 Watts
T6P11600100: 600 x 1000 = 844 Watts
T6P11600120: 600 x 1200 = 1013 Watts
T6P11600140: 600 x 1400 = 1182 Watts
T6P11600160: 600 x 1600 = 1350 Watts
T6P11900060: 900 x 0600 = 719 Watts
T6P11900080: 900 x 0800 = 959 Watts
T6P11900100: 900 x 1000 = 1199 Watts
T6P21300060: 300 x 0600 = 470 Watts
T6P21300080: 300 x 0800 = 626 Watts
T6P21300100: 300 x 1000 = 783 Watts
T6P21400060: 400 x 0600 = 593 Watts
T6P21400080: 400 x 0800 = 790 Watts
T6P21400100: 400 x 1000 = 988 Watts
T6P21600040: 600 x 0400 = 520 Watts
T6P21600060: 600 x 0600 = 781 Watts
T6P21600080: 600 x 0800 = 1041 Watts
T6P21600100: 600 x 1000 = 1301 Watts
T6P21600120: 600 x 1200 = 1561 Watts
T6P21600140: 600 x 1400 = 1821 Watts
T6P21600160: 600 x 1600 = 2082 Watts
T6P21900060: 900 x 0600 = 1061 Watts
T6P21900080: 900 x 0800 = 1415 Watts
T6P21900100: 900 x 1000 = 1769 Watts
T6P22300060: 300 x 0600 = 643 Watts
T6P22300080: 300 x 0800 = 857 Watts
T6P22300100: 300 x 1000 = 1071 Watts
T6P22400060: 400 x 0600 = 802 Watts
T6P22400080: 400 x 0800 = 1069 Watts
T6P22400100: 400 x 1000 = 1336 Watts
T6P22600040: 600 x 0400 = 668 Watts
T6P22600060: 600 x 0600 = 1001 Watts
T6P22600080: 600 x 0800 = 1335 Watts
T6P22600100: 600 x 1000 = 1669 Watts
T6P22600120: 600 x 1200 = 2003 Watts
T6P22600140: 600 x 1400 = 2337 Watts
T6P22600160: 600 x 1600 = 2670 Watts
T6P22900060: 900 x 0600 = 1349 Watts
T6P22900080: 900 x 0800 = 1798 Watts
T6P22900100: 900 x 1000 = 2248 Watts
T6P33300060: 300 x 0600 = 940 Watts
T6P33300080: 300 x 0800 = 1253 Watts
T6P33300100: 300 x 1000 = 1566 Watts
T6P33400060: 400 x 0600 = 1168 Watts
T6P33400080: 400 x 0800 = 1557 Watts
T6P33400100: 400 x 1000 = 1946 Watts
T6P33600040: 600 x 0400 = 967 Watts
T6P33600060: 600 x 0600 = 1451 Watts
T6P33600080: 600 x 0800 = 1934 Watts
T6P33600100: 600 x 1000 = 2418 Watts
T6P33600120: 600 x 1200 = 2902 Watts
T6P33600140: 600 x 1400 = 3385 Watts
T6P33600160: 600 x 1600 = 3869 Watts
T6P33900060: 900 x 0600 = 1895 Watts
T6P33900080: 900 x 0800 = 2527 Watts
T6P33900100: 900 x 1000 = 3159 Watts
Vertical radiator centrally connected

VERTICAL -CENTRALLY CONNECTED RADIATORS

high heating power and a wide range of colour options

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


VCC101500045: 1500 x 0450 = 650 Watts
VCC101500060: 1500 x 0600 = 867 Watts
VCC101800045: 1800 x 0450 = 765 Watts
VCC101800060: 1800 x 0600 = 1020 Watts
VCC101800075: 1800 x 0750 = 1275 Watts
VCC101950045: 1950 x 0450 = 819 Watts
VCC101950060: 1950 x 0600 = 1092 Watts
VCC101950075: 1950 x 0750 = 1365 Watts
VCC102100045: 2100 x 0450 = 876 Watts
VCC102100060: 2100 x 0600 = 1168 Watts
VCC102100075: 2100 x 0750 = 1460 Watts
VCC201800030: 1800 x 0300 = 819 Watts
VCC201800045: 1800 x 0450 = 1229 Watts
VCC201800060: 1800 x 0600 = 1638 Watts
VCC201800075: 1800 x 0750 = 2048 Watts
VCC201950030: 1950 x 0300 = 877 Watts
VCC201950045: 1950 x 0450 = 1315 Watts
VCC201950060: 1950 x 0600 = 1753 Watts
VCC201950075: 1950 x 0750 = 2192 Watts
VCC202100030: 2100 x 0300 = 935 Watts
VCC202100045: 2100 x 0450 = 1403 Watts
VCC202100060: 2100 x 0600 = 1870 Watts
VCC202100075: 2100 x 0750 = 2338 Watts

VCC211800030: 1800 x 0300 = 963 Watts
VCC211800045: 1800 x 0450 = 1445 Watts
VCC211800060: 1800 x 0600 = 1926 Watts
VCC211800075: 1800 x 0750 = 2408 Watts
VCC211950030: 1950 x 0300 = 1020 Watts
VCC211950045: 1950 x 0450 = 1530 Watts
VCC211950060: 1950 x 0600 = 2040 Watts
VCC211950075: 1950 x 0750 = 2550 Watts
VCC212100030: 2100 x 0300 = 1081 Watts
VCC212100045: 2100 x 0450 = 1622 Watts
VCC212100060: 2100 x 0600 = 2162 Watts
VCC212100075: 2100 x 0750 = 2703 Watts

VCC221800030: 1800 x 0300 = 1132 Watts
VCC221800045: 1800 x 0450 = 1698 Watts
VCC221800060: 1800 x 0600 = 2264 Watts
VCC221950030: 1950 x 0300 = 1192 Watts
VCC221950045: 1950 x 0450 = 1788 Watts
VCC221950060: 1950 x 0600 = 2384 Watts
VCC221950075: 1950 x 0750 = 2980 Watts
VCC222100030: 2100 x 0300 = 1252 Watts
VCC222100045: 2100 x 0450 = 1877 Watts
VCC222100060: 2100 x 0600 = 2503 Watts
VCC222100075: 2100 x 0750 = 3129 Watts
VCC222300075: 2300 x 0750 = 3329 Watts
Vertical plan radiator

PLAN-VERTICAL -CENTRALLY CONNECTED RADIATORS

high heating power and a wide range of colour options

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


PVC211800030: 1800 x 0300 = 886 Watts
PVC211800045: 1800 x 0450 = 1329 Watts
PVC211800060: 1800 x 0600 = 1772 Watts
PVC211800075: 1800 x 0750 = 2215 Watts
PVC211950030: 1950 x 0300 = 936 Watts
PVC211950045: 1950 x 0450 = 1405 Watts
PVC211950060: 1950 x 0600 = 1873 Watts
PVC211950075: 1950 x 0750 = 2341 Watts
PVC212100030: 2100 x 0300 = 978 Watts
PVC212100045: 2100 x 0450 = 1468 Watts
PVC212100060: 2100 x 0600 = 1957 Watts
PVC212100075: 2100 x 0750 = 2446 Watts
PVC221800030: 1800 x 0300 = 1046 Watts
PVC221800045: 1800 x 0450 = 1569 Watts
PVC221800060: 1800 x 0600 = 2092 Watts
PVC221950030: 1950 x 0300 = 1103 Watts
PVC221950045: 1950 x 0450 = 1654 Watts
PVC221950060: 1950 x 0600 = 2205 Watts
PVC221950075: 1950 x 0750 = 2756 Watts
PVC222100030: 2100 x 0300 = 1161 Watts
PVC222100045: 2100 x 0450 = 1742 Watts
PVC222100060: 2100 x 0600 = 2323 Watts
PVC222100075: 2100 x 0750 = 2903 Watts
Multi functional valve radiator

MULTI-FUNCTIONAL VALVE RADIATOR

High power and enormous flexibility regarding control.

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


MFV11300060: 300 x 0600 = 339 Watts
MFV11300080: 300 x 0800 = 452 Watts
MFV11300100: 300 x 1000 = 565 Watts
MFV11400060: 400 x 0600 = 425 Watts
MFV11400080: 400 x 0800 = 566 Watts
MFV11400100: 400 x 1000 = 708 Watts
MFV11600040: 600 x 0400 = 376 Watts
MFV11600060: 600 x 0600 = 563 Watts
MFV11600080: 600 x 0800 = 751 Watts
MFV11600100: 600 x 1000 = 939 Watts
MFV11600120: 600 x 1200 = 1127 Watts
MFV11600140: 600 x 1400 = 1315 Watts
MFV11600160: 600 x 1600 = 1502 Watts
MFV11900060: 900 x 0600 = 775 Watts
MFV11900080: 900 x 0800 = 1034 Watts
MFV11900100: 900 x 1000 = 1292 Watts
MFV21300060: 300 x 0600 = 503 Watts
MFV21300080: 300 x 0800 = 670 Watts
MFV21300100: 300 x 1000 = 838 Watts
MFV21400060: 400 x 0600 = 628 Watts
MFV21400080: 400 x 0800 = 838 Watts
MFV21400100: 400 x 1000 = 1047 Watts
MFV21600040: 600 x 0400 = 543 Watts
MFV21600060: 600 x 0600 = 814 Watts
MFV21600080: 600 x 0800 = 1086 Watts
MFV21600100: 600 x 1000 = 1357 Watts
MFV21600120: 600 x 1200 = 1628 Watts
MFV21600140: 600 x 1400 = 1900 Watts
MFV21600160: 600 x 1600 = 2171 Watts
MFV21900060: 900 x 0600 = 1118 Watts
MFV21900080: 900 x 0800 = 1491 Watts
MFV21900100: 900 x 1000 = 1864 Watts
MFV22300060: 300 x 0600 = 657 Watts
MFV22300080: 300 x 0800 = 876 Watts
MFV22300100: 300 x 1000 = 1095 Watts
MFV22400060: 400 x 0600 = 814 Watts
MFV22400080: 400 x 0800 = 1086 Watts
MFV22400100: 400 x 1000 = 1357 Watts
MFV22600040: 600 x 0400 = 685 Watts
MFV22600060: 600 x 0600 = 1028 Watts
MFV22600080: 600 x 0800 = 1370 Watts
MFV22600100: 600 x 1000 = 1713 Watts
MFV22600120: 600 x 1200 = 2056 Watts
MFV22600140: 600 x 1400 = 2398 Watts
MFV22600160: 600 x 1600 = 2741 Watts
MFV22900060: 900 x 0600 = 1378 Watts
MFV22900080: 900 x 0800 = 1837 Watts
MFV22900100: 900 x 1000 = 2296 Watts
MFV33300060: 300 x 0600 = 937 Watts
MFV33300080: 300 x 0800 = 1249 Watts
MFV33300100: 300 x 1000 = 1561 Watts
MFV33400060: 400 x 0600 = 1162 Watts
MFV33400080: 400 x 0800 = 1549 Watts
MFV33400100: 400 x 1000 = 1936 Watts
MFV33600040: 600 x 0400 = 981 Watts
MFV33600060: 600 x 0600 = 1472 Watts
MFV33600080: 600 x 0800 = 1962 Watts
MFV33600100: 600 x 1000 = 2453 Watts
MFV33600120: 600 x 1200 = 2944 Watts
MFV33600140: 600 x 1400 = 3434 Watts
MFV33600160: 600 x 1600 = 3925 Watts
MFV33900060: 900 x 0600 = 1933 Watts
MFV33900080: 900 x 0800 = 2577 Watts
MFV33900100: 900 x 1000 = 3221 Watts
Compact radiators

COMPACT RADIATORS

High performance, rapid room
heating and even heat distribution.

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


CR10400060: 0400 x 0600 = 266 Watts
CR10400080: 0400 x 0800 = 355 Watts
CR10400100: 0400 x 1000 = 444 Watts
CR10600040: 0600 x 0400 = 250 Watts
CR10600060: 0600 x 0600 = 375 Watts
CR10600080: 0600 x 0800 = 500 Watts
CR10600100: 0600 x 1000 = 625 Watts
CR10600120: 0600 x 1200 = 750 Watts
CR10600140: 0600 x 1400 = 875 Watts
CR10600160: 0600 x 1600 = 1000 Watts
CR10900060: 0900 x 0600 = 527 Watts
CR10900080: 0900 x 0800 = 702 Watts
CR10900100: 0900 x 1000 = 878 Watts
CR11400060: 0400 x 0600 = 425 Watts
CR11400080: 0400 x 0800 = 566 Watts
CR11400100: 0400 x 1000 = 708 Watts
CR11600040: 0600 x 0400 = 376 Watts
CR11600060: 0600 x 0600 = 563 Watts
CR11600080: 0600 x 0800 = 751 Watts
CR11600100: 0600 x 1000 = 939 Watts
CR11600120: 0600 x 1200 = 1127 Watts
CR11600140: 0600 x 1400 = 1315 Watts
CR11600160: 0600 x 1600 = 1502 Watts
CR11900060: 0900 x 0600 = 775 Watts
CR11900080: 0900 x 0800 = 1034 Watts
CR11900100: 0900 x 1000 = 1292 Watts
CR21400060: 0400 x 0600 = 628 Watts
CR21400080: 0400 x 0800 = 838 Watts
CR21400100: 0400 x 1000 = 1047 Watts
CR21600040: 0600 x 0400 = 543 Watts
CR21600060: 0600 x 0600 = 814 Watts
CR21600080: 0600 x 0800 = 1086 Watts
CR21600100: 0600 x 1000 = 1357 Watts
CR21600120: 0600 x 1200 = 1628 Watts
CR21600140: 0600 x 1400 = 1900 Watts
CR21600160: 0600 x 1600 = 2171 Watts
CR21900060: 0900 x 0600 = 1118 Watts
CR21900080: 0900 x 0800 = 1491 Watts
CR21900100: 0900 x 1000 = 1864 Watts
CR22400060: 0400 x 0600 = 814 Watts
CR22400080: 0400 x 0800 = 1086 Watts
CR22400100: 0400 x 1000 = 1357 Watts
CR22600040: 0600 x 0400 = 685 Watts
CR22600060: 0600 x 0600 = 1028 Watts
CR22600080: 0600 x 0800 = 1370 Watts
CR22600100: 0600 x 1000 = 1713 Watts
CR22600120: 0600 x 1200 = 2056 Watts
CR22600140: 0600 x 1400 = 2398 Watts
CR22600160: 0600 x 1600 = 2741 Watts
CR22900060: 0900 x 0600 = 1378 Watts
CR22900080: 0900 x 0800 = 1837 Watts
CR22900100: 0900 x 1000 = 2296 Watts
CR33400060: 0400 x 0600 = 1162 Watts
CR33400080: 0400 x 0800 = 1549 Watts
CR33400100: 0400 x 1000 = 1936 Watts
CR33600040: 0600 x 0400 = 981 Watts
CR33600060: 0600 x 0600 = 1472 Watts
CR33600080: 0600 x 0800 = 1962 Watts
CR33600100: 0600 x 1000 = 2453 Watts
CR33600120: 0600 x 1200 = 2944 Watts
CR33600140: 0600 x 1400 = 3434 Watts
CR33600160: 0600 x 1600 = 3925 Watts
CR33900060: 0900 x 0600 = 1933 Watts
CR33900080: 0900 x 0800 = 2577 Watts
CR33900100: 0900 x 1000 = 3221 Watts
hygiene t6

HYGIENE T6 RADIATORS

Proved suitability for the installation in rooms with particular hygienic requirements.

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


HT610300060: 300 x 0600 = 209 Watts
HT610300080: 300 x 0800 = 278 Watts
HT610300100: 300 x 1000 = 348 Watts
HT610400060: 400 x 0600 = 266 Watts
HT610400080: 400 x 0800 = 355 Watts
HT610400100: 400 x 1000 = 444 Watts
HT610600040: 600 x 0400 = 250 Watts
HT610600060: 600 x 0600 = 375 Watts
HT610600080: 600 x 0800 = 500 Watts
HT610600100: 600 x 1000 = 625 Watts
HT610600120: 600 x 1200 = 750 Watts
HT610600140: 600 x 1400 = 875 Watts
HT610600160: 600 x 1600 = 1000 Watts
HT610900060: 900 x 0600 = 527 Watts
HT610900080: 900 x 0800 = 702 Watts
HT610900100: 900 x 1000 = 878 Watts
HT620300060: 300 x 0600 = 354 Watts
HT620300080: 300 x 0800 = 472 Watts
HT620300100: 300 x 1000 = 590 Watts
HT620400060: 400 x 0600 = 447 Watts
HT620400080: 400 x 0800 = 596 Watts
HT620400100: 400 x 1000 = 745 Watts
HT620600040: 600 x 0400 = 414 Watts
HT620600060: 600 x 0600 = 621 Watts
HT620600080: 600 x 0800 = 828 Watts
HT620600100: 600 x 1000 = 1035 Watts
HT620600120: 600 x 1200 = 1242 Watts
HT620600140: 600 x 1400 = 1449 Watts
HT620600160: 600 x 1600 = 1656 Watts
HT620900060: 900 x 0600 = 864 Watts
HT620900080: 900 x 0800 = 1152 Watts
HT620900100: 900 x 1000 = 1440 Watts
HT630300060: 300 x 0600 = 512 Watts
HT630300080: 300 x 0800 = 682 Watts
HT630300100: 300 x 1000 = 853 Watts
HT630400060: 400 x 0600 = 641 Watts
HT630400080: 400 x 0800 = 855 Watts
HT630400100: 400 x 1000 = 1069 Watts
HT630600040: 600 x 0400 = 591 Watts
HT630600060: 600 x 0600 = 886 Watts
HT630600080: 600 x 0800 = 1182 Watts
HT630600100: 600 x 1000 = 1477 Watts
HT630600120: 600 x 1200 = 1772 Watts
HT630600140: 600 x 1400 = 2068 Watts
HT630600160: 600 x 1600 = 2363 Watts
HT630900060: 900 x 0600 = 1235 Watts
HT630900080: 900 x 0800 = 1646 Watts
HT630900100: 900 x 1000 = 2058 Watts
Hygiene plan radiator

HYGIENE T6-PLAN CENTRALLY CONNECTED RADIATORS

Proved suitability for the installation in rooms with particular hygienic requirements.

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


HT610300040: 300 x 0400 = 124 Watts
HT610300060: 300 x 0600 = 186 Watts
HT610300080: 300 x 0800 = 248 Watts
HT610400060: 400 x 0600 = 238 Watts
HT610400080: 400 x 0800 = 317 Watts
HT610400100: 400 x 1000 = 396 Watts
HT610600040: 600 x 0400 = 220 Watts
HT610600060: 600 x 0600 = 330 Watts
HT610600080: 600 x 0800 = 440 Watts
HT610600100: 600 x 1000 = 550 Watts
HT610600120: 600 x 1200 = 660 Watts
HT610600140: 600 x 1400 = 770 Watts
HT610600160: 600 x 1600 = 880 Watts
HT610900040: 900 x 0400 = 298 Watts
HT610900060: 900 x 0600 = 448 Watts
HT610900080: 900 x 0800 = 597 Watts
HT620300040: 300 x 0400 = 224 Watts
HT620300060: 300 x 0600 = 335 Watts
HT620300080: 300 x 0800 = 447 Watts
HT620400060: 400 x 0600 = 419 Watts
HT620400080: 400 x 0800 = 558 Watts
HT620400100: 400 x 1000 = 698 Watts
HT620600040: 600 x 0400 = 383 Watts
HT620600060: 600 x 0600 = 574 Watts
HT620600080: 600 x 0800 = 766 Watts
HT620600100: 600 x 1000 = 957 Watts
HT620600120: 600 x 1200 = 1148 Watts
HT620600140: 600 x 1400 = 1340 Watts
HT620600160: 600 x 1600 = 1531 Watts
HT620600180: 600 x 1800 = 1723 Watts
HT620900040: 900 x 0400 = 526 Watts
HT620900060: 900 x 0600 = 789 Watts
HT620900080: 900 x 0800 = 1052 Watts
HT630300040: 300 x 0400 = 334 Watts
HT630300060: 300 x 0600 = 500 Watts
HT630300080: 300 x 0800 = 667 Watts
HT630400060: 400 x 0600 = 617 Watts
HT630400080: 400 x 0800 = 823 Watts
HT630400100: 400 x 1000 = 1029 Watts
HT630600040: 600 x 0400 = 557 Watts
HT630600060: 600 x 0600 = 836 Watts
HT630600080: 600 x 0800 = 1114 Watts
HT630600100: 600 x 1000 = 1393 Watts
HT630600120: 600 x 1200 = 1672 Watts
HT630600140: 600 x 1400 = 1950 Watts
HT630600160: 600 x 1600 = 2229 Watts
HT630900040: 900 x 0400 = 764 Watts
HT630900060: 900 x 0600 = 1145 Watts
HT630900080: 900 x 0800 = 1527 Watts
Hygiene compact radiator

HYGIENE COMPACT RADIATORS

Hygiene radiators constitute a dust-free way to achieve a comfortable level of warmth

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


HCR10600092: 0600 x 0920 = 575 Watts
HCR20400060: 0400 x 0600 = 447 Watts
HCR20400080: 0400 x 0800 = 596 Watts
HCR20400100: 0400 x 1000 = 745 Watts
HCR20600040: 0600 x 0400 = 414 Watts
HCR20600060: 0600 x 0600 = 621 Watts
HCR20600080: 0600 x 0800 = 828 Watts
HCR20600100: 0600 x 1000 = 1035 Watts
HCR20600120: 0600 x 1200 = 1242 Watts
HCR20600140: 0600 x 1400 = 1449 Watts
HCR20600160: 0600 x 1600 = 1656 Watts
HCR20900060: 0900 x 0600 = 864 Watts
HCR20900080: 0900 x 0800 = 1152 Watts
HCR20900100: 0900 x 1000 = 1440 Watts
HCR30400060: 0400 x 0600 = 641 Watts
HCR30400080: 0400 x 0800 = 855 Watts
HCR30400100: 0400 x 1000 = 1069 Watts
HCR30600040: 0600 x 0400 = 591 Watts
HCR30600060: 0600 x 0600 = 886 Watts
HCR30600080: 0600 x 0800 = 1182 Watts
HCR30600100: 0600 x 1000 = 1477 Watts
HCR30600120: 0600 x 1200 = 1772 Watts
HCR30600140: 0600 x 1400 = 2068 Watts
HCR30600160: 0600 x 1600 = 2363 Watts
HCR30900060: 0900 x 0600 = 1235 Watts
HCR30900080: 0900 x 0800 = 1646 Watts
HCR30900100: 0900 x 1000 = 2058 Watts

STRAIGHT DESIGN RADIATORS

Sewa design radiator

SEWA

Design radiator

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


SEWA:
SWDRS1471600: 1471 x 0600 = 779 Watts
SWDRS1685600: 1685 x 0600 = 914 Watts
SWDRS1685700: 1685 x 0700 = 1045 Watts

Nero design radiator

NERO

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


NERO:
NRDRS1019530: 1019 x 0530 = 451 Watts
NRDRS1419530: 1419 x 0530 = 614 Watts
NRDRS1419630: 1419 x 0630 = 721 Watts
NRDRS1819530: 1819 x 0530 = 794 Watts
NRDRS1819630: 1819 x 0630 = 968 Watts

Fatala spa design radiator

FATALA-VM SPA

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


FATALA-VM SPA:
FVSD0C1200505: 1200 x 0505 = 583 Watts
FVSD0C1200605: 1200 x 0605 = 704 Watts
FVSD0C1200755: 1200 x 0755 = 887 Watts
FVSD0C1500505: 1500 x 0505 = 699 Watts
FVSD0C1500605: 1500 x 0605 = 844 Watts
FVSD0C1500755: 1500 x 0755 = 1064 Watts
FVSD0C1800505: 1800 x 0505 = 855 Watts
FVSD0C1800605: 1800 x 0605 = 1032 Watts
FVSD0C1800755: 1800 x 0755 = 1300 Watts

Bawa-VM design radiator

BAWA-VM

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


BAWA VM:
BWVMW0800500: 800 x 0500 = 420 Watts
BWVMW0800600: 800 x 0600 = 493 Watts
BWVMW0800750: 800 x 0750 = 600 Watts
BWVMW0800900: 800 x 0900 = 704 Watts
BWVMW1200500: 1200 x 0500 = 629 Watts
BWVMW1200600: 1200 x 0600 = 738 Watts
BWVMW1200750: 1200 x 0750 = 898 Watts
BWVMW1200900: 1200 x 0900 = 1053 Watts
BWVMW1800500: 1800 x 0500 = 885 Watts
BWVMW1800600: 1800 x 0600 = 1038 Watts
BWVMW1800750: 1800 x 0750 = 1263 Watts
BWVMW1800900: 1800 x 0900 = 1482 Watts

Arun-t design radiator

ARUN-T

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


ARUN T:
ATDRW1200500: 1200 x 0500 = 885 Watts
ATDRW1200600: 1200 x 0600 = 1061 Watts
ATDRW1200750: 1200 x 0750 = 1326 Watts
ATDRW1200900: 1200 x 0900 = 1590 Watts
ATDRW1800500: 1800 x 0500 = 1222 Watts
ATDRW1800600: 1800 x 0600 = 1466 Watts
ATDRW1800750: 1800 x 0750 = 1831 Watts
ATDRW1800900: 1800 x 0900 = 2196 Watts
ATDRW2200500: 2200 x 0500 = 1482 Watts
ATDRW2200600: 2200 x 0600 = 1771 Watts
ATDRW2200750: 2200 x 0750 = 2204 Watts
ATDRW2200900: 2200 x 0900 = 2635 Watts

Bawa design radiator

BAWA

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


BAWA:
BWDRW0800500: 800 x 0500 = 420 Watts
BWDRW0800600: 800 x 0600 = 493 Watts
BWDRW0800750: 800 x 0750 = 600 Watts
BWDRW0800900: 800 x 0900 = 704 Watts
BWDRW1200500: 1200 x 0500 = 629 Watts
BWDRW1200600: 1200 x 0600 = 738 Watts
BWDRW1200750: 1200 x 0750 = 898 Watts
BWDRW1200900: 1200 x 0900 = 1053 Watts
BWDRW1800500: 1800 x 0500 = 885 Watts
BWDRW1800600: 1800 x 0600 = 1038 Watts
BWDRW1800750: 1800 x 0750 = 1263 Watts
BWDRW1800900: 1800 x 0900 = 1482 Watts

Bawa vm spa design radiator

BAWA-SPA

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


BAWA-SPA:
BVSD0C1200510: 1200 x 0510 = 629 Watts
BVSD0C1200610: 1200 x 0610 = 738 Watts
BVSD0C1200760: 1200 x 0760 = 898 Watts
BVSD0C1500510: 1500 x 0510 = 747 Watts
BVSD0C1500610: 1500 x 0610 = 876 Watts
BVSD0C1500760: 1500 x 0760 = 1066 Watts
BVSD0C1800510: 1800 x 0510 = 885 Watts
BVSD0C1800610: 1800 x 0610 = 1038 Watts
BVSD0C1800760: 1800 x 0760 = 1263 Watts

Bawa-t VM design radiator

BAWA-T VM

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


BAWA-T VM:
BTVMW1200500: 1200 x 0500 = 885 Watts
BTVMW1200600: 1200 x 0600 = 1061 Watts
BTVMW1200750: 1200 x 0750 = 1326 Watts
BTVMW1200900: 1200 x 0900 = 1590 Watts
BTVMW1800500: 1800 x 0500 = 1222 Watts
BTVMW1800600: 1800 x 0600 = 1466 Watts
BTVMW1800750: 1800 x 0750 = 1831 Watts
BTVMW1800900: 1800 x 0900 = 2196 Watts

Bawa e design radiator

BAWA-E

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at 60℃

Dimensions: Height x Width (mm)


BAWA-E
BWEOW0800500: 800 x 0500 = 300 Watts
BWEOW1200500: 1200 x 0500 = 400 Watts
BWEOW1200600: 1200 x 0600 = 600 Watts
BWEOW1800600: 1800 x 0600 = 900 Watts

Fatala-E design radiator

FATALA-E

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at 60℃

Dimensions: Height x Width (mm)


FUEOW1200500: 1200 x 500 = 400 Watts
FUEOW1200600: 1200 x 600 = 600 Watts
FUEOW1800600: 1800 x 600 = 900 Watts
FUEOCH1200500: 1200 x 500 = 300 Watts
FUEOCH1200600: 1200 x 600 = 400 Watts
FUEOCH1800600: 1800 x 600 = 600 Watts
Kasai design radiator

KASAI

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


KASAI:
KSDRW1000600: 1000 x 0600 = 499 Watts
KSDRW1300600: 1300 x 0600 = 613 Watts
KSDRW1300750: 1300 x 0750 = 739 Watts
KSDRW1500600: 1500 x 0600 = 724 Watts
KSDRW1500750: 1500 x 0750 = 870 Watts
KSDRW1500900: 1500 x 0900 = 1030 Watts
KSDRW1800750: 1800 x 0750 = 1008 Watts
KSDRW1800900: 1800 x 0900 = 1194 Watts

Lowa-VM design radiator

LOWA-VM

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


LOWA-VM:
LDRW0790500: 790 x 0500 = 416 Watts
LDRW0790600: 790 x 0600 = 487 Watts
LDRW0790700: 790 x 0700 = 557 Watts
LDRW0790800: 790 x 0800 = 626 Watts
LDRW1222500: 1222 x 0500 = 608 Watts
LDRW1222600: 1222 x 0600 = 713 Watts
LDRW1222700: 1222 x 0700 = 815 Watts
LDRW1222800: 1222 x 0800 = 915 Watts
LDRW1510500: 1510 x 0500 = 727 Watts
LDRW1510600: 1510 x 0600 = 852 Watts
LDRW1510700: 1510 x 0700 = 974 Watts
LDRW1510800: 1510 x 0800 = 1094 Watts

CURVED DESIGN RADIATORS

Cavally - design radiator

CAVALLY

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


CAVALLY:
CVDRW0800500: 0800 x 0500 = 440 Watts
CVDRW0800600: 0800 x 0600 = 528 Watts
CVDRW0800750: 0800 x 0750 = 659 Watts
CVDRW0800900: 0800 x 0900 = 790 Watts
CVDRW1200500: 1200 x 0500 = 649 Watts
CVDRW1200600: 1200 x 0600 = 778 Watts
CVDRW1200750: 1200 x 0750 = 972 Watts
CVDRW1200900: 1200 x 0900 = 1165 Watts
CVDRW1800500: 1800 x 0500 = 920 Watts
CVDRW1800600: 1800 x 0600 = 1103 Watts
CVDRW1800750: 1800 x 0750 = 1378 Watts
CVDRW1800900: 1800 x 0900 = 1651 Watts

Cavally-VM design radiator

CAVALLY-VM

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


CAVALLY-VM:
CVVMW0800500: 0800 x 0500 = 440 Watts
CVVMW0800600: 0800 x 0600 = 528 Watts
CVVMW0800750: 0800 x 0750 = 659 Watts
CVVMW0800900: 0800 x 0900 = 790 Watts
CVVMW1200500: 1200 x 0500 = 649 Watts
CVVMW1200600: 1200 x 0600 = 778 Watts
CVVMW1200750: 1200 x 0750 = 972 Watts
CVVMW1200900: 1200 x 0900 = 1165 Watts
CVVMW1800500: 1800 x 0500 = 920 Watts
CVVMW1800600: 1800 x 0600 = 1103 Watts
CVVMW1800750: 1800 x 0750 = 1378 Watts
CVVMW1800900: 1800 x 0900 = 1651 Watts

Fulda - design radiator

FULDA

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


FULDA:
FUDRW0800500: 800 x 0500 = 405 Watts
FUDRW0800600: 800 x 0600 = 474 Watts
FUDRW0800750: 800 x 0750 = 574 Watts
FUDRW0800900: 800 x 0900 = 671 Watts
FUDRW1200500: 1200 x 0500 = 620 Watts
FUDRW1200600: 1200 x 0600 = 724 Watts
FUDRW1200750: 1200 x 0750 = 877 Watts
FUDRW1200900: 1200 x 0900 = 1025 Watts
FUDRW1800500: 1800 x 0500 = 870 Watts
FUDRW1800600: 1800 x 0600 = 1021 Watts
FUDRW1800750: 1800 x 0750 = 1241 Watts
FUDRW1800900: 1800 x 0900 = 1456 Watts

Fulda-VM design radiator

FULDA-VM

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


FULDA-VM:
FUVMW1200500: 1200 x 0500 = 620 Watts
FUVMW1200600: 1200 x 0600 = 724 Watts
FUVMW1200750: 1200 x 0750 = 877 Watts
FUVMW1800500: 1800 x 0500 = 870 Watts
FUVMW1800600: 1800 x 0600 = 1021 Watts
FUVMW1800750: 1800 x 0750 = 1241 Watts

Fulda- E design radiator

FULDA-E

Design radiator

Quick downloads

Dimensions and heat outputs

Velino - design radiator

VELINO

Design radiator

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


VELINO:
VLDRW16001000: 0600 x 1000 = 1699 Watts
VLDRW18001000: 0800 x 1000 = 1895 Watts
VLDRW18001200: 0800 x 1200 = 2274 Watts
VLDRW1600500: 1600 x 0500 = 850 Watts
VLDRW1600800: 1600 x 0800 = 1359 Watts
VLDRW1800500: 1800 x 0500 = 948 Watts
VLDRW1800800: 1800 x 0800 = 1516 Watts

TOWEL WARMERS

DION - towel warmer

DION

Towel warmer

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


DIONTW0700050: 0700 x 0500 = 374 Watts
DIONTW0700060: 0700 x 0600 = 437 Watts
DIONTW0700075: 0700 x 0750 = 529 Watts
DIONTW0700090: 0700 x 0900 = 617 Watts
DIONTW1100050: 1100 x 0500 = 568 Watts
DIONTW1100060: 1100 x 0600 = 663 Watts
DIONTW1100075: 1100 x 0750 = 802 Watts
DIONTW1100090: 1100 x 0900 = 937 Watts
DIONTW1800050: 1800 x 0500 = 886 Watts
DIONTW1800060: 1800 x 0600 = 1035 Watts
DIONTW1800075: 1800 x 0750 = 1252 Watts
DIONTW1800090: 1800 x 0900 = 1462 Watts
DICHTW1100050: 1100 x 0500 = 388 Watts
DICHTW1100060: 1100 x 0600 = 452 Watts
DICHTW1800050: 1800 x 0500 = 603 Watts
DICHTW1800060: 1800 x 0600 = 701 Watts



DION VM towel warmer

DION-VM

Towel warmer

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


DIVMTW0700050: 0700 x 0500 = 374 Watts
DIVMTW0700060: 0700 x 0600 = 437 Watts
DIVMTW0700075: 0700 x 0750 = 529 Watts
DIVMTW0700090: 0700 x 0900 = 617 Watts
DIVMTW1100050: 1100 x 0500 = 568 Watts
DIVMTW1100060: 1100 x 0600 = 663 Watts
DIVMTW1100075: 1100 x 0750 = 802 Watts
DIVMTW1100090: 1100 x 0900 = 937 Watts
DIVMTW1800050: 1800 x 0500 = 886 Watts
DIVMTW1800060: 1800 x 0600 = 1035 Watts
DIVMTW1800075: 1800 x 0750 = 1252 Watts
DIVMTW1800090: 1800 x 0900 = 1462 Watts
DVMCTW1100050: 1100 x 0500 = 388 Watts
DVMCTW1100060: 1100 x 0600 = 452 Watts
DVMCTW1800050: 1800 x 0500 = 603 Watts
DVMCTW1800060: 1800 x 0600 = 701 Watts
Della e towel warmer

DELLA-E

Towel warmer

Quick downloads

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

DELLA-E:
DETWED1100050: 1100 x 0500 = 512 Watts
DETWED1100060: 1100 x 0600 = 604 Watts
DETWED1800050: 1800 x 0500 = 782 Watts
DETWED1800060: 1800 x 0600 = 921 Watts

Avonmore towel warmer

AVONMORE

Towel warmer

Quick downloads

Dimensions and heat outputs

COLUMN RADIATORS

Laserline standard column radiator

LASERLINE STANDARD

Column radiator

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


LLS2C04000400: 400 x 0400 = 261 Watts
LLS2C04000600: 400 x 0600 = 391 Watts
LLS2C04000800: 400 x 0800 = 522 Watts
LLS2C06000400: 600 x 0400 = 376 Watts
LLS2C06000600: 600 x 0600 = 564 Watts
LLS2C06000800: 600 x 0800 = 752 Watts
LLS2C06001000: 600 x 1000 = 940 Watts
LLS2C06001200: 600 x 1200 = 1128 Watts
LLS2C09000400: 900 x 0400 = 545 Watts
LLS2C09000600: 900 x 0600 = 818 Watts
LLS2C09000800: 900 x 0800 = 1091 Watts
LLS2C09001000: 900 x 1000 = 1364 Watts
LLS2C12000400: 1200 x 0400 = 714 Watts
LLS2C12000600: 1200 x 0600 = 1072 Watts
LLS2C12000800: 1200 x 0800 = 1429 Watts
LLS2C12001000: 1200 x 1000 = 1787 Watts
LLS3C04000400: 400 x 0400 = 364 Watts
LLS3C04000600: 400 x 0600 = 546 Watts
LLS3C04000800: 400 x 0800 = 728 Watts
LLS3C06000400: 600 x 0400 = 520 Watts
LLS3C06000600: 600 x 0600 = 780 Watts
LLS3C06000800: 600 x 0800 = 1041 Watts
LLS3C06001000: 600 x 1000 = 1301 Watts
LLS3C06001200: 600 x 1200 = 1561 Watts
LLS3C09000400: 900 x 0400 = 748 Watts
LLS3C09000600: 900 x 0600 = 1122 Watts
LLS3C09000800: 900 x 0800 = 1497 Watts
LLS3C09001000: 900 x 1000 = 1871 Watts
LLS3C12000400: 1200 x 400 = 973 Watts
LLS3C12000600: 1200 x 600 = 1460 Watts
LLS3C12000800: 1200 x 800 = 1947 Watts
LLS3C12001000: 1200 x 1000 = 2434 Watts
LLS4C04000400: 400 x 0400 = 467 Watts
LLS4C04000600: 400 x 0600 = 700 Watts
LLS4C04000800: 400 x 0800 = 934 Watts
LLS4C06000400: 600 x 0400 = 664 Watts
LLS4C06000600: 600 x 0600 = 997 Watts
LLS4C06000800: 600 x 0800 = 1329 Watts
LLS4C06001000: 600 x 1000 = 1662 Watts
LLS4C06001200: 600 x 1200 = 1994 Watts
LLS4C09000400: 900 x 0400 = 951 Watts
LLS4C09000600: 900 x 0600 = 1427 Watts
LLS4C09000800: 900 x 0800 = 1902 Watts
LLS4C09001000: 900 x 1000 = 2378 Watts
LLS4C12000400: 1200 x 400 = 1232 Watts
LLS4C12000600: 1200 x 600 = 1848 Watts
LLS4C12000800: 1200 x 800 = 2464 Watts
LLS4C12001000: 1200 x 1000 = 3080 Watts
LLS5C04000400: 400 x 0400 = 574 Watts
LLS5C04000600: 400 x 0600 = 862 Watts
LLS5C04000800: 400 x 0800 = 1149 Watts
LLS5C06000400: 600 x 0400 = 819 Watts
LLS5C06000600: 600 x 0600 = 1229 Watts
LLS5C06000800: 600 x 0800 = 1639 Watts
LLS5C06001000: 600 x 1000 = 2049 Watts
LLS5C06001200: 600 x 1200 = 2459 Watts
LLS5C09000400: 900 x 0400 = 1174 Watts
LLS5C09000600: 900 x 0600 = 1761 Watts
LLS5C09000800: 900 x 0800 = 2348 Watts
LLS5C09001000: 900 x 1000 = 2935 Watts
LLS5C12000400: 1200 x 400 = 1521 Watts
LLS5C12000600: 1200 x 600 = 2282 Watts
LLS5C12000800: 1200 x 800 = 3042 Watts
LLS5C12001000: 1200 x 1000 = 3803 Watts
LLS6C04000400: 400 x 0400 = 682 Watts
LLS6C04000600: 400 x 0600 = 1023 Watts
LLS6C04000800: 400 x 0800 = 1365 Watts
LLS6C06000400: 600 x 0400 = 974 Watts
LLS6C06000600: 600 x 0600 = 1461 Watts
LLS6C06000800: 600 x 0800 = 1949 Watts
LLS6C06001000: 600 x 1000 = 2436 Watts
LLS6C06001200: 600 x 1200 = 2923 Watts
LLS6C09000400: 900 x 0400 = 1397 Watts
LLS6C09000600: 900 x 0600 = 2095 Watts
LLS6C09000800: 900 x 0800 = 2794 Watts
LLS6C09001000: 900 x 1000 = 3493 Watts
LLS6C12000400: 1200 x 400 = 1810 Watts
LLS6C12000600: 1200 x 600 = 2715 Watts
LLS6C12000800: 1200 x 800 = 3620 Watts
LLS6C12001000: 1200 x 1000 = 4525 Watts
Laserline centrally connected column radiators

LASERLINE CENTRALLY CONNECTED VALVE RADIATOR

Column radiator

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


LLC2C04000400: 400 x 0400 = 261 Watts
LLC2C04000600: 400 x 0600 = 391 Watts
LLC2C04000800: 400 x 0800 = 522 Watts
LLC2C06000400: 600 x 0400 = 376 Watts
LLC2C06000600: 600 x 0600 = 564 Watts
LLC2C06000800: 600 x 0800 = 752 Watts
LLC2C06001000: 600 x 1000 = 940 Watts
LLC2C06001200: 600 x 1200 = 1128 Watts
LLC2C09000400: 900 x 0400 = 545 Watts
LLC2C09000600: 900 x 0600 = 818 Watts
LLC2C09000800: 900 x 0800 = 1091 Watts
LLC2C09001000: 900 x 1000 = 1364 Watts
LLC2C12000400: 1200 x 0400 = 714 Watts
LLC2C12000600: 1200 x 0600 = 1072 Watts
LLC2C12000800: 1200 x 0800 = 1429 Watts
LLC3C04000400: 400 x 0400 = 364 Watts
LLC3C04000600: 400 x 0600 = 546 Watts
LLC3C04000800: 400 x 0800 = 728 Watts
LLC3C06000400: 600 x 0400 = 520 Watts
LLC3C06000600: 600 x 0600 = 781 Watts
LLC3C06000800: 600 x 0800 = 1041 Watts
LLC3C06001000: 600 x 1000 = 1301 Watts
LLC3C06001200: 600 x 1200 = 1562 Watts
LLC3C09000400: 900 x 0400 = 748 Watts
LLC3C09000600: 900 x 0600 = 1122 Watts
LLC3C09000800: 900 x 0800 = 1497 Watts
LLC3C09001000: 900 x 1000 = 1871 Watts
LLC3C12000400: 1200 x 0400 = 973 Watts
LLC3C12000600: 1200 x 0600 = 1460 Watts
LLC3C12000800: 1200 x 0800 = 1947 Watts
LLC4C04000400: 400 x 0400 = 467 Watts
LLC4C04000600: 400 x 0600 = 700 Watts
LLC4C04000800: 400 x 0800 = 934 Watts
LLC4C06000400: 600 x 0400 = 664 Watts
LLC4C06000600: 600 x 0600 = 997 Watts
LLC4C06000800: 600 x 0800 = 1330 Watts
LLC4C06001000: 600 x 1000 = 1662 Watts
LLC4C06001200: 600 x 1200 = 1995 Watts
LLC4C09000400: 900 x 0400 = 951 Watts
LLC4C09000600: 900 x 0600 = 1427 Watts
LLC4C09000800: 900 x 0800 = 1902 Watts
LLC4C09001000: 900 x 1000 = 2378 Watts
LLC4C12000400: 1200 x 0400 = 1232 Watts
LLC4C12000600: 1200 x 0600 = 1848 Watts
LLC4C12000800: 1200 x 0800 = 2464 Watts
LLC5C04000400: 400 x 0400 = 574 Watts
LLC5C04000600: 400 x 0600 = 862 Watts
LLC5C04000800: 400 x 0800 = 1149 Watts
LLC5C06000400: 600 x 0400 = 820 Watts
LLC5C06000600: 600 x 0600 = 1229 Watts
LLC5C06000800: 600 x 0800 = 1640 Watts
LLC5C06001000: 600 x 1000 = 2050 Watts
LLC5C06001200: 600 x 1200 = 2460 Watts
LLC5C09000400: 900 x 0400 = 1174 Watts
LLC5C09000600: 900 x 0600 = 1761 Watts
LLC5C09000800: 900 x 0800 = 2348 Watts
LLC5C09001000: 900 x 1000 = 2935 Watts
LLC5C12000400: 1200 x 0400 = 1521 Watts
LLC5C12000600: 1200 x 0600 = 2282 Watts
LLC5C12000800: 1200 x 0800 = 3042 Watts
LLC6C04000400: 400 x 0400 = 682 Watts
LLC6C04000600: 400 x 0600 = 1023 Watts
LLC6C04000800: 400 x 0800 = 1365 Watts
LLC6C06000400: 600 x 0400 = 974 Watts
LLC6C06000600: 600 x 0600 = 1461 Watts
LLC6C06000800: 600 x 0800 = 1949 Watts
LLC6C06001000: 600 x 1000 = 2437 Watts
LLC6C06001200: 600 x 1200 = 2924 Watts
LLC6C09000400: 900 x 0400 = 1397 Watts
LLC6C09000600: 900 x 0600 = 2095 Watts
LLC6C09000800: 900 x 0800 = 2794 Watts
LLC6C09001000: 900 x 1000 = 3493 Watts
LLC6C12000400: 1200 x 0400 = 1810 Watts
LLC6C12000600: 1200 x 0600 = 2715 Watts
LLC6C12000800: 1200 x 0800 = 3620 Watts
Laserline architecture bar column radiator

LASERLINE ARCHITECTURE BAR

Column radiator

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


LLA4C07500700: 750 x 0700 = 1416 Watts
LLA4C07500900: 750 x 0900 = 1821 Watts
LLA4C07501100: 750 x 1100 = 2225 Watts
LLA4C09000700: 900 x 0700 = 1665 Watts
LLA4C09000900: 900 x 0900 = 2141 Watts
LLA4C09001100: 900 x 1100 = 2616 Watts
LLA5C07500700: 750 x 0700 = 1747 Watts
LLA5C07500900: 750 x 0900 = 2246 Watts
LLA5C07501100: 750 x 1100 = 2746 Watts
LLA5C09000700: 900 x 0700 = 2055 Watts
LLA5C09000900: 900 x 0900 = 2642 Watts
LLA5C09001100: 900 x 1100 = 3229 Watts
Laserline architecture bench column radiator

LASERLINE ARCHITECTURE BENCH

Column radiator

Dimensions and heat outputs

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)


6 COLUMNS:
LLA6C02001500: 200 x 1500 = 1411 Watts
LLA6C02001800: 200 x 1800 = 1696 Watts
LLA6C02002000: 200 x 2000 = 1886 Watts
LLA6C02002500: 200 x 2500 = 2362 Watts
LLA6C02002800: 200 x 2800 = 2648 Watts
LLA6C02501500: 250 x 1500 = 1742 Watts
LLA6C02501800: 250 x 1800 = 2097 Watts
LLA6C02502000: 250 x 2000 = 2334 Watts
LLA6C02502500: 250 x 2500 = 2929 Watts
LLA6C02502800: 250 x 2800 = 3287 Watts
LLA6C03001500: 300 x 1500 = 1934 Watts
LLA6C03001800: 300 x 1800 = 2337 Watts
LLA6C03002000: 300 x 2000 = 2606 Watts
LLA6C03002500: 300 x 2500 = 3285 Watts
LLA6C03002800: 300 x 2800 = 3695 Watts
LLA6C03501500: 350 x 1500 = 2204 Watts
LLA6C03501800: 350 x 1800 = 2670 Watts
LLA6C03502000: 350 x 2000 = 2982 Watts
LLA6C03502500: 350 x 2500 = 3770 Watts
LLA6C03502800: 350 x 2800 = 4247 Watts

CONVECTORS AND TRENCH CONVECTORS

Vonaris convectors

VONARIS CONVECTORS
Horizontal & vertical

Convectors

Dimensions and heat outputs - horizontal centrally connected

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


VHVM103580600: 358 x 0600 = 236 Watts
VHVM103580800: 358 x 0800 = 315 Watts
VHVM103581000: 358 x 1000 = 394 Watts
VHVM104300600: 430 x 0600 = 275 Watts
VHVM104300800: 430 x 0800 = 366 Watts
VHVM104301000: 430 x 1000 = 458 Watts
VHVM104301200: 430 x 1200 = 550 Watts
VHVM106460600: 646 x 0600 = 393 Watts
VHVM106460800: 646 x 0800 = 524 Watts
VHVM106461000: 646 x 1000 = 655 Watts
VHVM106461200: 646 x 1200 = 786 Watts
VHVM107900600: 790 x 0600 = 477 Watts
VHVM107900800: 790 x 0800 = 636 Watts
VHVM107901000: 790 x 1000 = 795 Watts
VHVM113580600: 358 x 0600 = 375 Watts
VHVM113580800: 358 x 0800 = 500 Watts
VHVM113581000: 358 x 1000 = 625 Watts
VHVM114300600: 430 x 0600 = 431 Watts
VHVM114300800: 430 x 0800 = 574 Watts
VHVM114301000: 430 x 1000 = 718 Watts
VHVM114301200: 430 x 1200 = 862 Watts
VHVM116460600: 646 x 0600 = 579 Watts
VHVM116460800: 646 x 0800 = 772 Watts
VHVM116461000: 646 x 1000 = 965 Watts
VHVM116461200: 646 x 1200 = 1158 Watts
VHVM117900600: 790 x 0600 = 671 Watts
VHVM117900800: 790 x 0800 = 894 Watts
VHVM117901000: 790 x 1000 = 1118 Watts
VHVM203580600: 358 x 0600 = 392 Watts
VHVM203580800: 358 x 0800 = 523 Watts
VHVM203581000: 358 x 1000 = 654 Watts
VHVM204300600: 430 x 0600 = 454 Watts
VHVM204300800: 430 x 0800 = 606 Watts
VHVM204301000: 430 x 1000 = 757 Watts
VHVM204301200: 430 x 1200 = 908 Watts
VHVM206460600: 646 x 0600 = 638 Watts
VHVM206460800: 646 x 0800 = 850 Watts
VHVM206461000: 646 x 1000 = 1063 Watts
VHVM206461200: 646 x 1200 = 1276 Watts
VHVM207900600: 790 x 0600 = 763 Watts
VHVM207900800: 790 x 0800 = 1017 Watts
VHVM207901000: 790 x 1000 = 1271 Watts
VHVM223580600: 358 x 0600 = 660 Watts
VHVM223580800: 358 x 0800 = 880 Watts
VHVM223581000: 358 x 1000 = 1100 Watts
VHVM224300600: 430 x 0600 = 761 Watts
VHVM224300800: 430 x 0800 = 1014 Watts
VHVM224301000: 430 x 1000 = 1268 Watts
VHVM224301200: 430 x 1200 = 1522 Watts
VHVM226460600: 646 x 0600 = 992 Watts
VHVM226460800: 646 x 0800 = 1323 Watts
VHVM226461000: 646 x 1000 = 1654 Watts
VHVM226461200: 646 x 1200 = 1985 Watts
VHVM227900600: 790 x 0600 = 1124 Watts
VHVM227900800: 790 x 0800 = 1499 Watts
VHVM227901000: 790 x 1000 = 1874 Watts
VHVM341420800: 142 x 0800 = 762 Watts
VHVM341421000: 142 x 1000 = 953 Watts
VHVM341421200: 142 x 1200 = 1144 Watts
VHVM342140800: 214 x 0800 = 1086 Watts
VHVM342141000: 214 x 1000 = 1357 Watts
VHVM342141200: 214 x 1200 = 1628 Watts
VHVM342860800: 286 x 0800 = 1293 Watts
VHVM342861000: 286 x 1000 = 1616 Watts
VHVM342861200: 286 x 1200 = 1939 Watts
VHVM461420800: 142 x 0800 = 1146 Watts
VHVM461421000: 142 x 1000 = 1433 Watts
VHVM461421200: 142 x 1200 = 1720 Watts
VHVM462140800: 214 x 0800 = 1516 Watts
VHVM462141000: 214 x 1000 = 1895 Watts
VHVM462141200: 214 x 1200 = 2274 Watts
VHVM462860800: 286 x 0800 = 1886 Watts
VHVM462861000: 286 x 1000 = 2357 Watts
VHVM462861200: 286 x 1200 = 2828 Watts



Dimensions and heat outputs - horizontal

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


VHV113580600: 358 x 0600 = 400 Watts
VHV113580800: 358 x 0800 = 534 Watts
VHV113581000: 358 x 1000 = 667 Watts
VHV114300600: 430 x 0600 = 456 Watts
VHV114300800: 430 x 0800 = 608 Watts
VHV114301000: 430 x 1000 = 760 Watts
VHV114301200: 430 x 1200 = 912 Watts
VHV116460600: 646 x 0600 = 593 Watts
VHV116460800: 646 x 0800 = 791 Watts
VHV116461000: 646 x 1000 = 989 Watts
VHV116461200: 646 x 1200 = 1187 Watts
VHV117900600: 790 x 0600 = 663 Watts
VHV117900800: 790 x 0800 = 884 Watts
VHV117901000: 790 x 1000 = 1105 Watts
VHV203580600: 358 x 0600 = 392 Watts
VHV203580800: 358 x 0800 = 523 Watts
VHV203581000: 358 x 1000 = 654 Watts
VHV204300600: 430 x 0600 = 454 Watts
VHV204300800: 430 x 0800 = 606 Watts
VHV204301000: 430 x 1000 = 757 Watts
VHV204301200: 430 x 1200 = 908 Watts
VHV206460600: 646 x 0600 = 638 Watts
VHV206460800: 646 x 0800 = 850 Watts
VHV206461000: 646 x 1000 = 1063 Watts
VHV206461200: 646 x 1200 = 1276 Watts
VHV207900600: 790 x 0600 = 763 Watts
VHV207900800: 790 x 0800 = 1017 Watts
VHV207901000: 790 x 1000 = 1271 Watts
VHV223580600: 358 x 0600 = 718 Watts
VHV223580800: 358 x 0800 = 958 Watts
VHV223581000: 358 x 1000 = 1197 Watts
VHV224300600: 430 x 0600 = 806 Watts
VHV224300800: 430 x 0800 = 1074 Watts
VHV224301000: 430 x 1000 = 1343 Watts
VHV224301200: 430 x 1200 = 1612 Watts
VHV226460600: 646 x 0600 = 1019 Watts
VHV226460800: 646 x 0800 = 1359 Watts
VHV226461000: 646 x 1000 = 1699 Watts
VHV226461200: 646 x 1200 = 2039 Watts
VHV227900600: 790 x 0600 = 1132 Watts
VHV227900800: 790 x 0800 = 1509 Watts
VHV227901000: 790 x 1000 = 1886 Watts
VHV231420600: 142 x 0600 = 478 Watts
VHV231420800: 142 x 0800 = 638 Watts
VHV231421000: 142 x 1000 = 797 Watts
VHV231421200: 142 x 1200 = 956 Watts
VHV232140600: 214 x 0600 = 621 Watts
VHV232140800: 214 x 0800 = 828 Watts
VHV232141000: 214 x 1000 = 1035 Watts
VHV232141200: 214 x 1200 = 1242 Watts
VHV232860600: 286 x 0600 = 757 Watts
VHV232860800: 286 x 0800 = 1009 Watts
VHV232861000: 286 x 1000 = 1261 Watts
VHV232861200: 286 x 1200 = 1513 Watts
VHV341420600: 142 x 0600 = 630 Watts
VHV341420800: 142 x 0800 = 840 Watts
VHV341421000: 142 x 1000 = 1050 Watts
VHV341421200: 142 x 1200 = 1260 Watts
VHV342140600: 214 x 0600 = 836 Watts
VHV342140800: 214 x 0800 = 1115 Watts
VHV342141000: 214 x 1000 = 1394 Watts
VHV342141200: 214 x 1200 = 1673 Watts
VHV342860600: 286 x 0600 = 1034 Watts
VHV342860800: 286 x 0800 = 1378 Watts
VHV342861000: 286 x 1000 = 1723 Watts
VHV342861200: 286 x 1200 = 2068 Watts
VHV351420600: 142 x 0600 = 718 Watts
VHV351420800: 142 x 0800 = 958 Watts
VHV351421000: 142 x 1000 = 1197 Watts
VHV351421200: 142 x 1200 = 1436 Watts
VHV352140600: 214 x 0600 = 991 Watts
VHV352140800: 214 x 0800 = 1321 Watts
VHV352141000: 214 x 1000 = 1651 Watts
VHV352141200: 214 x 1200 = 1981 Watts
VHV352860600: 286 x 0600 = 1183 Watts
VHV352860800: 286 x 0800 = 1577 Watts
VHV352861000: 286 x 1000 = 1971 Watts
VHV352861200: 286 x 1200 = 2365 Watts
VHV461420600: 142 x 0600 = 872 Watts
VHV461420800: 142 x 0800 = 1163 Watts
VHV461421000: 142 x 1000 = 1454 Watts
VHV461421200: 142 x 1200 = 1745 Watts
VHV462140600: 214 x 0600 = 1243 Watts
VHV462140800: 214 x 0800 = 1658 Watts
VHV462141000: 214 x 1000 = 2072 Watts
VHV462141200: 214 x 1200 = 2486 Watts
VHV462860600: 286 x 0600 = 1468 Watts
VHV462860800: 286 x 0800 = 1958 Watts
VHV462861000: 286 x 1000 = 2447 Watts
VHV462861200: 286 x 1200 = 2936 Watts
VHVS472140600: 214 x 0600 = 1381 Watts
VHVS472140800: 214 x 0800 = 1842 Watts
VHVS472141000: 214 x 1000 = 2302 Watts
VHVS472141200: 214 x 1200 = 2762 Watts
VHVS472860600: 286 x 0600 = 1600 Watts
VHVS472860800: 286 x 0800 = 2134 Watts
VHVS472861000: 286 x 1000 = 2667 Watts
VHVS472861200: 286 x 1200 = 3200 Watts

Dimensions and heat outputs - vertical centrally connected

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


VHVM101000502: 1000 x 0502 = 537 Watts
VHVM101000502: 1000 x 0502 = 537 Watts
VHVM101000646: 1000 x 0646 = 691 Watts
VHVM101000790: 1000 x 0790 = 845 Watts
VHVM101200502: 1200 x 0502 = 645 Watts
VHVM101200646: 1200 x 0646 = 829 Watts
VHVM101200790: 1200 x 0790 = 1014 Watts
VHVM101400502: 1400 x 0502 = 756 Watts
VHVM101400646: 1400 x 0646 = 973 Watts
VHVM101400790: 1400 x 0790 = 1190 Watts
VHVM101600502: 1600 x 0502 = 872 Watts
VHVM101600646: 1600 x 0646 = 1123 Watts
VHVM101600790: 1600 x 0790 = 1373 Watts
VHVM101800502: 1800 x 0502 = 993 Watts
VHVM101800646: 1800 x 0646 = 1278 Watts
VHVM101800790: 1800 x 0790 = 1563 Watts
VHVM111000502: 1000 x 0502 = 668 Watts
VHVM111000646: 1000 x 0646 = 860 Watts
VHVM111000790: 1000 x 0790 = 1051 Watts
VHVM111200502: 1200 x 0502 = 774 Watts
VHVM111200646: 1200 x 0646 = 995 Watts
VHVM111200790: 1200 x 0790 = 1217 Watts
VHVM111400502: 1400 x 0502 = 882 Watts
VHVM111400646: 1400 x 0646 = 1135 Watts
VHVM111400790: 1400 x 0790 = 1388 Watts
VHVM111600502: 1600 x 0502 = 993 Watts
VHVM111600646: 1600 x 0646 = 1278 Watts
VHVM111600790: 1600 x 0790 = 1563 Watts
VHVM111800502: 1800 x 0502 = 1109 Watts
VHVM111800646: 1800 x 0646 = 1427 Watts
VHVM111800790: 1800 x 0790 = 1745 Watts
VHVM201000502: 1000 x 0502 = 924 Watts
VHVM201000646: 1000 x 0646 = 1189 Watts
VHVM201000790: 1000 x 0790 = 1454 Watts
VHVM201200502: 1200 x 0502 = 1105 Watts
VHVM201200646: 1200 x 0646 = 1422 Watts
VHVM201200790: 1200 x 0790 = 1740 Watts
VHVM201400502: 1400 x 0502 = 1288 Watts
VHVM201400646: 1400 x 0646 = 1658 Watts
VHVM201400790: 1400 x 0790 = 2027 Watts
VHVM201600502: 1600 x 0502 = 1472 Watts
VHVM201600646: 1600 x 0646 = 1894 Watts
VHVM201600790: 1600 x 0790 = 2316 Watts
VHVM201800502: 1800 x 0502 = 1657 Watts
VHVM201800646: 1800 x 0646 = 2132 Watts
VHVM201800790: 1800 x 0790 = 2608 Watts
VHVM211000502: 1000 x 0502 = 1034 Watts
VHVM211000646: 1000 x 0646 = 1330 Watts
VHVM211000790: 1000 x 0790 = 1627 Watts
VHVM211200502: 1200 x 0502 = 1215 Watts
VHVM211200646: 1200 x 0646 = 1564 Watts
VHVM211200790: 1200 x 0790 = 1913 Watts
VHVM211400502: 1400 x 0502 = 1403 Watts
VHVM211400646: 1400 x 0646 = 1806 Watts
VHVM211400790: 1400 x 0790 = 2208 Watts
VHVM211600502: 1600 x 0502 = 1598 Watts
VHVM211600646: 1600 x 0646 = 2057 Watts
VHVM211600790: 1600 x 0790 = 2515 Watts
VHVM211800502: 1800 x 0502 = 1801 Watts
VHVM211800646: 1800 x 0646 = 2318 Watts
VHVM211800790: 1800 x 0790 = 2835 Watts

Dimensions and heat outputs - vertical

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


VSV1016000502: 1600 x 0502 = 872 Watts
VSV1016000646: 1600 x 0646 = 1123 Watts
VSV1016000790: 1600 x 0790 = 1373 Watts
VSV1018000502: 1800 x 0502 = 993 Watts
VSV1018000646: 1800 x 0646 = 1278 Watts
VSV1018000790: 1800 x 0790 = 1563 Watts
VSV1020000502: 2000 x 0502 = 1120 Watts
VSV1020000646: 2000 x 0646 = 1442 Watts
VSV1020000790: 2000 x 0790 = 1763 Watts
VSV1116000502: 1600 x 0502 = 993 Watts
VSV1116000646: 1600 x 0646 = 1278 Watts
VSV1116000790: 1600 x 0790 = 1563 Watts
VSV1118000502: 1800 x 0502 = 1109 Watts
VSV1118000646: 1800 x 0646 = 1427 Watts
VSV1118000790: 1800 x 0790 = 1745 Watts
VSV1120000502: 2000 x 0502 = 1230 Watts
VSV1120000646: 2000 x 0646 = 1583 Watts
VSV1120000790: 2000 x 0790 = 1936 Watts
VSV2016000502: 1600 x 0502 = 1472 Watts
VSV2016000646: 1600 x 0646 = 1894 Watts
VSV2016000790: 1600 x 0790 = 2316 Watts
VSV2018000502: 1800 x 0502 = 1657 Watts
VSV2018000646: 1800 x 0646 = 2132 Watts
VSV2018000790: 1800 x 0790 = 2608 Watts
VSV2020000502: 2000 x 0502 = 1843 Watts
VSV2020000646: 2000 x 0646 = 2372 Watts
VSV2020000790: 2000 x 0790 = 2901 Watts
VSV2116000502: 1600 x 0502 = 1598 Watts
VSV2116000646: 1600 x 0646 = 2057 Watts
VSV2116000790: 1600 x 0790 = 2515 Watts
VSV2118000502: 1800 x 0502 = 1801 Watts
VSV2118000646: 1800 x 0646 = 2318 Watts
VSV2118000790: 1800 x 0790 = 2835 Watts
VSV2120000502: 2000 x 0502 = 2014 Watts
VSV2120000646: 2000 x 0646 = 2592 Watts
VSV2120000790: 2000 x 0790 = 3169 Watts

KONTEC CONVECTORS
Horizontal & vertical

Convectors

Dimensions and heat outputs - horizontal KH

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


KH103580600: 358 x 0600 = 236 Watts
KH103580800: 358 x 0800 = 315 Watts
KH103581000: 358 x 1000 = 394 Watts
KH104300600: 430 x 0600 = 275 Watts
KH104300800: 430 x 0800 = 366 Watts
KH104301000: 430 x 1000 = 458 Watts
KH105020600: 502 x 0600 = 314 Watts
KH105020800: 502 x 0800 = 418 Watts
KH105021000: 502 x 1000 = 523 Watts
KH105740600: 574 x 0600 = 353 Watts
KH105740800: 574 x 0800 = 470 Watts
KH105741000: 574 x 1000 = 588 Watts
KH106460600: 646 x 0600 = 393 Watts
KH106460800: 646 x 0800 = 524 Watts
KH106461000: 646 x 1000 = 655 Watts
KH107900600: 790 x 0600 = 477 Watts
KH107900800: 790 x 0800 = 636 Watts
KH107901000: 790 x 1000 = 795 Watts
KH113580600: 358 x 0600 = 400 Watts
KH113580800: 358 x 0800 = 534 Watts
KH113581000: 358 x 1000 = 667 Watts
KH114300600: 430 x 0600 = 456 Watts
KH114300800: 430 x 0800 = 608 Watts
KH114301000: 430 x 1000 = 760 Watts
KH115020600: 502 x 0600 = 507 Watts
KH115020800: 502 x 0800 = 676 Watts
KH115021000: 502 x 1000 = 845 Watts
KH115740600: 574 x 0600 = 553 Watts
KH115740800: 574 x 0800 = 737 Watts
KH115741000: 574 x 1000 = 921 Watts
KH116460600: 646 x 0600 = 593 Watts
KH116460800: 646 x 0800 = 791 Watts
KH116461000: 646 x 1000 = 989 Watts
KH117900600: 790 x 0600 = 663 Watts
KH117900800: 790 x 0800 = 884 Watts
KH117901000: 790 x 1000 = 1105 Watts
KH203600600: 360 x 0600 = 392 Watts
KH203600800: 360 x 0800 = 523 Watts
KH203601000: 360 x 1000 = 654 Watts
KH204300600: 430 x 0600 = 454 Watts
KH204300800: 430 x 0800 = 606 Watts
KH204301000: 430 x 1000 = 757 Watts
KH205000600: 500 x 0600 = 515 Watts
KH205000800: 500 x 0800 = 687 Watts
KH205001000: 500 x 1000 = 859 Watts
KH205700600: 570 x 0600 = 576 Watts
KH205700800: 570 x 0800 = 768 Watts
KH205701000: 570 x 1000 = 960 Watts
KH206500600: 650 x 0600 = 638 Watts
KH206500800: 650 x 0800 = 850 Watts
KH206501000: 650 x 1000 = 1063 Watts
KH207900600: 790 x 0600 = 763 Watts
KH207900800: 790 x 0800 = 1017 Watts
KH207901000: 790 x 1000 = 1271 Watts
KH223600600: 360 x 0600 = 718 Watts
KH223600800: 360 x 0800 = 958 Watts
KH223601000: 360 x 1000 = 1197 Watts
KH224300600: 430 x 0600 = 806 Watts
KH224300800: 430 x 0800 = 1074 Watts
KH224301000: 430 x 1000 = 1343 Watts
KH225000600: 500 x 0600 = 884 Watts
KH225000800: 500 x 0800 = 1179 Watts
KH225001000: 500 x 1000 = 1474 Watts
KH225700600: 570 x 0600 = 955 Watts
KH225700800: 570 x 0800 = 1274 Watts
KH225701000: 570 x 1000 = 1592 Watts
KH226500600: 650 x 0600 = 1019 Watts
KH226500800: 650 x 0800 = 1359 Watts
KH226501000: 650 x 1000 = 1699 Watts
KH227900600: 790 x 0600 = 1132 Watts
KH227900800: 790 x 0800 = 1509 Watts
KH227901000: 790 x 1000 = 1886 Watts

Dimensions and heat outputs - horizontal KK

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


KK112140600: 214 x 0600 = 278 Watts
KK112140800: 214 x 0800 = 371 Watts
KK112141000: 214 x 1000 = 464 Watts
KK112141200: 214 x 1200 = 557 Watts
KK112860600: 286 x 0600 = 346 Watts
KK112860800: 286 x 0800 = 462 Watts
KK112861000: 286 x 1000 = 577 Watts
KK112861200: 286 x 1200 = 692 Watts
KK201400600: 140 x 0600 = 196 Watts
KK201400800: 140 x 0800 = 262 Watts
KK201401000: 140 x 1000 = 327 Watts
KK201401200: 140 x 1200 = 392 Watts
KK202100600: 210 x 0600 = 265 Watts
KK202100800: 210 x 0800 = 354 Watts
KK202101000: 210 x 1000 = 442 Watts
KK202101200: 210 x 1200 = 530 Watts
KK202800600: 280 x 0600 = 330 Watts
KK202800800: 280 x 0800 = 440 Watts
KK202801000: 280 x 1000 = 550 Watts
KK202801200: 280 x 1200 = 660 Watts
KK220700600: 70 x 0600 = 254 Watts
KK220700800: 70 x 0800 = 339 Watts
KK220701000: 70 x 1000 = 424 Watts
KK221400600: 140 x 0600 = 385 Watts
KK221400800: 140 x 0800 = 513 Watts
KK221401000: 140 x 1000 = 641 Watts
KK222100600: 210 x 0600 = 503 Watts
KK222100800: 210 x 0800 = 670 Watts
KK222101000: 210 x 1000 = 838 Watts
KK222800600: 280 x 0600 = 619 Watts
KK222800800: 280 x 0800 = 826 Watts
KK222801000: 280 x 1000 = 1032 Watts
KK230700600: 70 x 0600 = 314 Watts
KK230700800: 70 x 0800 = 419 Watts
KK230701000: 70 x 1000 = 524 Watts
KK231420600: 142 x 0600 = 478 Watts
KK231420800: 142 x 0800 = 638 Watts
KK231421000: 142 x 1000 = 797 Watts
KK232140600: 214 x 0600 = 621 Watts
KK232140800: 214 x 0800 = 828 Watts
KK232141000: 214 x 1000 = 1035 Watts
KK232860600: 286 x 0600 = 757 Watts
KK232860800: 286 x 0800 = 1009 Watts
KK232861000: 286 x 1000 = 1261 Watts
KK340700600: 70 x 0600 = 397 Watts
KK340700800: 70 x 0800 = 529 Watts
KK340701000: 70 x 1000 = 661 Watts
KK341400600: 140 x 0600 = 630 Watts
KK341400800: 140 x 0800 = 840 Watts
KK341401000: 140 x 1000 = 1050 Watts
KK342100600: 210 x 0600 = 836 Watts
KK342100800: 210 x 0800 = 1115 Watts
KK342101000: 210 x 1000 = 1394 Watts
KK342800600: 280 x 0600 = 1034 Watts
KK342800800: 280 x 0800 = 1378 Watts
KK342801000: 280 x 1000 = 1723 Watts
KK350700600: 70 x 0600 = 485 Watts
KK350700800: 70 x 0800 = 647 Watts
KK350701000: 70 x 1000 = 809 Watts
KK351420600: 142 x 0600 = 718 Watts
KK351420800: 142 x 0800 = 958 Watts
KK351421000: 142 x 1000 = 1197 Watts
KK352140600: 214 x 0600 = 991 Watts
KK352140800: 214 x 0800 = 1321 Watts
KK352141000: 214 x 1000 = 1651 Watts
KK352860600: 286 x 0600 = 1183 Watts
KK352860800: 286 x 0800 = 1577 Watts
KK352861000: 286 x 1000 = 1971 Watts
KK460700600: 70 x 0600 = 570 Watts
KK460700800: 70 x 0800 = 760 Watts
KK460701000: 70 x 1000 = 950 Watts
KK461400600: 140 x 0600 = 872 Watts
KK461400800: 140 x 0800 = 1163 Watts
KK461401000: 140 x 1000 = 1454 Watts
KK462100600: 210 x 0600 = 1243 Watts
KK462100800: 210 x 0800 = 1658 Watts
KK462101000: 210 x 1000 = 2072 Watts
KK462800600: 280 x 0600 = 1468 Watts
KK462800800: 280 x 0800 = 1958 Watts
KK462801000: 280 x 1000 = 2447 Watts
KKS470700600: 70 x 0600 = 592 Watts
KKS470700800: 70 x 0800 = 789 Watts
KKS470701000: 70 x 1000 = 986 Watts
KKS471400600: 140 x 0600 = 913 Watts
KKS471400800: 140 x 0800 = 1218 Watts
KKS471401000: 140 x 1000 = 1522 Watts
KKS472100600: 210 x 0600 = 1381 Watts
KKS472100800: 210 x 0800 = 1842 Watts
KKS472101000: 210 x 1000 = 2302 Watts
KKS472800600: 280 x 0600 = 1600 Watts
KKS472800800: 280 x 0800 = 2134 Watts
KKS472801000: 280 x 1000 = 2667 Watts
KK580700600: 70 x 0600 = 614 Watts
KK580700800: 70 x 0800 = 818 Watts
KK580701000: 70 x 1000 = 1023 Watts
KK581400600: 140 x 0600 = 995 Watts
KK581400800: 140 x 0800 = 1327 Watts
KK581401000: 140 x 1000 = 1659 Watts
KK582100600: 210 x 0600 = 1555 Watts
KK582100800: 210 x 0800 = 2074 Watts
KK582101000: 210 x 1000 = 2592 Watts
KK582800600: 280 x 0600 = 1813 Watts
KK582800800: 280 x 0800 = 2418 Watts
KK582801000: 280 x 1000 = 3022 Watts

Dimensions and heat outputs - vertical

Radiator power data in watts, in accordance with DIN EN 442 at (75/65/20) - 75℃ Flow Temperature, 65℃ Return Temperature and 20℃ Room Temperature.

Dimensions: Height x Width (mm)

Full list of dimensions and outputs can be found in product downloads.


KS101600358: 1600 x 0358 = 622 Watts
KS101600502: 1600 x 0502 = 872 Watts
KS101600646: 1600 x 0646 = 1123 Watts
KS101600790: 1600 x 0790 = 1373 Watts
KS101800358: 1800 x 0358 = 708 Watts
KS101800502: 1800 x 0502 = 993 Watts
KS101800646: 1800 x 0646 = 1278 Watts
KS101800790: 1800 x 0790 = 1563 Watts
KS102000358: 2000 x 0358 = 799 Watts
KS102000502: 2000 x 0502 = 1120 Watts
KS102000646: 2000 x 0646 = 1442 Watts
KS102000790: 2000 x 0790 = 1763 Watts
KS102200358: 2200 x 0358 = 893 Watts
KS102200502: 2200 x 0502 = 1252 Watts
KS102200646: 2200 x 0646 = 1612 Watts
KS102200790: 2200 x 0790 = 1971 Watts
KS111600358: 1600 x 0358 = 708 Watts
KS111600502: 1600 x 0502 = 993 Watts
KS111600646: 1600 x 0646 = 1278 Watts
KS111600790: 1600 x 0790 = 1563 Watts
KS111800358: 1800 x 0358 = 791 Watts
KS111800502: 1800 x 0502 = 1109 Watts
KS111800646: 1800 x 0646 = 1427 Watts
KS111800790: 1800 x 0790 = 1745 Watts
KS112000358: 2000 x 0358 = 877 Watts
KS112000502: 2000 x 0502 = 1230 Watts
KS112000646: 2000 x 0646 = 1583 Watts
KS112000790: 2000 x 0790 = 1936 Watts
KS112200358: 2200 x 0358 = 967 Watts
KS112200502: 2200 x 0502 = 1356 Watts
KS112200646: 2200 x 0646 = 1745 Watts
KS112200790: 2200 x 0790 = 2134 Watts
KS201600358: 1600 x 0358 = 1050 Watts
KS201600502: 1600 x 0502 = 1472 Watts
KS201600646: 1600 x 0646 = 1894 Watts
KS201600790: 1600 x 0790 = 2316 Watts
KS201800358: 1800 x 0358 = 1182 Watts
KS201800502: 1800 x 0502 = 1657 Watts
KS201800646: 1800 x 0646 = 2132 Watts
KS201800790: 1800 x 0790 = 2608 Watts
KS202000358: 2000 x 0358 = 1315 Watts
KS202000502: 2000 x 0502 = 1843 Watts
KS202000646: 2000 x 0646 = 2372 Watts
KS202000790: 2000 x 0790 = 2901 Watts
KS202200358: 2200 x 0358 = 1448 Watts
KS202200502: 2200 x 0502 = 2031 Watts
KS202200646: 2200 x 0646 = 2614 Watts
KS202200790: 2200 x 0790 = 3196 Watts
KS211600358: 1600 x 0358 = 1140 Watts
KS211600502: 1600 x 0502 = 1598 Watts
KS211600646: 1600 x 0646 = 2057 Watts
KS211600790: 1600 x 0790 = 2515 Watts
KS211800358: 1800 x 0358 = 1285 Watts
KS211800502: 1800 x 0502 = 1801 Watts
KS211800646: 1800 x 0646 = 2318 Watts
KS211800790: 1800 x 0790 = 2835 Watts
KS212000358: 2000 x 0358 = 1436 Watts
KS212000502: 2000 x 0502 = 2014 Watts
KS212000646: 2000 x 0646 = 2592 Watts
KS212000790: 2000 x 0790 = 3169 Watts
KS212200358: 2200 x 0358 = 1595 Watts
KS212200502: 2200 x 0502 = 2236 Watts
KS212200646: 2200 x 0646 = 2878 Watts
KS212200790: 2200 x 0790 = 3519 Watts
Intratherm convectors

KONTEC CONVECTORS
Type FMK, F1T and F1P

The Intratherm trench heating convectors provide excellent performance with their natural or fan assisted convection and soundless operation

Dimensions and heat outputs

 Full list of dimensions and outputs can be found in product downloads.

UNDERFLOOR HEATING

Kelox fb multilayer piping

KELOX FB - UNDERFLOOR HEATING

Underfloor heating - multilayer piping

Kelox fb fixing underfloor heating

KELOX FB FIXING

Simple solutions for mounting underfloor heating pipe networks

Kelox fb heating controllers

KELOX FB HEATING CONTROLLERS

KE KELIT offers a range of control systems, both wireless and wired, for your surface and underfloor heating systems

CEILING COOLING

Coolfix ceiling cooling

COOLFIX - SURFACE COOLING SYSTEM

The COOLFIX surface cooling system aims to improve the thermal comfort for residents in a building

RADIATORS ACCESSORIES

Simplex baseboard system

SIMPLEX BASEBOARD SYSTEM

With our patented mounting bracket, the baseboard is pressed custom-fit against the wall and held in place

Connection valves

RADIATOR CONNECTION VALVES

A complete and comprehensive range of connection valves for plug-in, screw-in and clamping for every application

Startec 4 thermostatic heads

RADIATOR CONNECTION VALVES

Suitable for use with thermostatic valves and compact radiators with valves

Quick downloads

No Downloads available for this product.

Design line thermostatic heads

DESIGN LINE
Valve bodies and thermostatic heads

Intelligent solutions with a sophisticated design, suitable for any radiator

Quick downloads

Lockshields radiator accessories

LOCKSHIELDS

Our radiator connections can be shut off for maintenance without affecting the heating system

Compression adapters

COMPRESSION ADAPTERS

Hardly any other compression adapter is as easy to use as the Simplex compression adapter

Radiator plugs

RADIATOR PLUGS

The range includes self-sealing blind, reducing, vent and drain plugs for radiators

Radiator problem solvers

RADIATOR PROBLEM SOLVERS

Our problem solvers are the right assistants for any tricky situation

RESIDENTIAL PUMP GROUPS

Residential pump groups

RESIDENTIAL PUMP GROUPS

Edition 8 residential pump groups offer solutions to heating systems up to 70kW

LARGE SCALE PUMP GROUPS

Large scale pump groups

LARGE SCALE PUMP GROUPS

Complete modular systems for heating up to 2300kW with pump capacities up to 100m³/h

VALVES

Ball valves

KFE BALL VALVES

Available in different versions for heating systems, domestic water systems and solar systems

Balancing valves

BALANCING & CONTROL VALVES

Since 1994, Nexus Valve has been providing the commercial HVAC industry with valves of the highest quality

Quick downloads

There are no downloads available for this product.

Pump and socket ball valves

PUMP & SOCKET BALL VALVES

Various handle versions, full bore clearance in the ball valve, thermometer handle

EXPANSION VESSELS

Expansion vessels

FLEXCON EXPANSION VESSELS

A comprehensive range of diaphragm expansion vessels

Expansion automats

EXPANSION AUTOMATS &
PRESSURISATION EQUIPMENT

Expansion Automats balance the system pressure, using a highly efficient vessel design and control equipment

Potable water installations expansion vessels

EXPANSION VESSELS - POTABLE WATER INSTALLATIONS

These expansion vessels can be applied in combination with all hot water calorifiers and as surge vessels in pressure boosting systems

WATER HEATERS AND STORAGE VESSELS

water heaters buffer tanks and calorfiers

WATER HEATERS & STORAGE VESSELS

Water heaters, storage vessels, buffer tanks and calorfiers

Accessories potable water installations

ACCESSORIES FOR POTABLE WATER INSTALLATIONS

Safety valves, pressure reducing valves, water shock arrestors, wall mounting and more

Water heaters and storage vessels accessories

ACCESSORIES FOR WATER HEATERS & STORAGE VESSELS

With a product range that includes ribbed-tube heat exchangers, insulation fittings and capillary dip tubes for temperature sensors

HVAC ACCESSORIES

Accessories for heating and cooling

ACCESSORIES FOR HEATING & COOLING

Safety valves, filling devices, pressure gauges, dosing pots and more

Flexible connections

FLEXIBLE HOSES CONNECTIONS

For use in the heating, solar and sanitary sectors

Labeling systems

LABELING SYSTEMS

Mark your pipes properly easily and practically without tools using our system

FIXING TECHNOLOGY

Universal mounting clamps

UNIVERSAL MOUNTING CLAMPS

KE KELIT offer the New Zealand market the most comprehensive range of universal mounting clips for pipes and tubes

Wall mounted clips for pipes

WALL MOUNTED CLIPS

Designed for installing threaded tubes, sprinkler pipes, thin wall steel tubes and copper pipes

Hangers for pipes and sprinklers

PIPE HANGERS & SPRINKLER CLIPS

A complete solution for mounting threaded tubes, thin-wall steel pipes, copper pipes, plastic pipes and rail structures safely, easily and reliably

Rail and rail accessories

RAIL AND RAIL ACCESSORIES

Installing suspension systems or wall-bracket systems quickly and efficiently is easy with Flamco rails and accessories

Mounting accessories for pipes

MOUNTING ACCESSORIES

A solution for all conditions and pipe materials including fixed-point installations

Stainless stel mounting material

STAINLESS STEEL MOUNTING MATERIAL

Ideal for use, not only in HVAC installations, but also in process industries where stainless steel pipe systems are specified

Pipe escutcheons

PIPE ESCUTCHEONS

Flamco pipe escutcheons ensures that the installation is completed professionally and is pleasing to the eye

Flamco falx PV panel mounting system

FLAMCO FALX - PV PANELS MOUNTING SYSTEM

Flamco has a new innovative solution for the installation of PV panels on flat roofs: Flamco Falx.

Quick downloads

Clevis pipe hangers

CLEVIS PIPE HANGERS

A comprehensive range of pipe hangers, supports and accessories, many of which are UL Listed and have FM approval

VENTING RANGE AND AUTOMATIC AIR AND DIRT SEPARATORS

Air dirt separators

VENTING RANGE & AUTOMATIC AIR AND DIRT SEPARATORS

Extract air and solid particles from the water, i.e. coalescence, flow velocity reduction and pressure drop

FLAMCO T-PLUS

Flamco T-plus pipe branching system

FLAMCO T-PLUS - PIPE BRANCHING SYSTEM

The T-Plus is an ideal product for the expansion, conversion or overhaul of an existing system
